LEx Key Features

The LEx series is a high-performance, low-power BLE SoC that supports the Bluetooth 5.0 full protocol stack, SIG mesh and private mesh, and can be applied to scenarios that require a large number of nodes to access smart homes and smart buildings.

• Industrial control level BLE SoC, support BLE 5.1 full protocol stack;
• Built-in high speed memory FLASH 1024/512kB, 64kB SRAM;
• Industrial grade product operating temperature range: -40℃~+105℃;
• Support a variety of packaging forms, QFN32/QFN48/SOP16/SSOP24;
• Contains a 32-bit MCU core, clock frequency is adjustable, up to 64MHz;
• RF performance indicators:
• RX sensitivity up to -105 DBM
• Max +13dBm TX power
• 117dBm link gain ensures good signal coverage
• Ultra-low power design, standby current as low as 1.1μA under SRAM and RTC operation;
• Supports various profiles defined by L2CAP, GAP, GATT, SMP and SIG organizations.
• Integrated rich peripherals, including complementary PWM output, capacitive touch interface, high-precision ADC, AES/DES/ECC security unit, high-speed serial port, etc.

APPLICATION

• Universal Bluetooth products
• Wearable application
• Intelligent building
• Smart home
• Intelligent travel
• HID
• PC Controller
